LARA Winders are THE NEW GENERATION of Core WINDERS .
We do design the curing system , the core winder...built-up for our customers, everything what is necessary for the core production .

For any related questions , we would appreciate to get in cooperation with you .

Contact details for information :
Tel        : +90 262 654 18 13
Fax       : +90 212 355 07 25
email: info@core-winder.com




                                                       Read More

    Core Winding solutions and Technologies:

    We are able to produce
    Toroidal Core sizes
    id-od : 40 - 900 mm
The High Speed
Fully Automatic
Toroidal Core Winder
of LARA
MAN2010
The Fully Automatic CORE Winder

F615
The curing System



CORE WINDING SOLUTIONS
F615
The PC controlled Curing Oven
- The cost Saving Solution
- Extreme precise temperature control
-Traceability option..
Read More

MAN2010 , Core Winding Machine for Toroidal Core Production  : The fully automatic winding machine for the manufacture of toroids made from grain oriented steel for small transformers, transmitters, instrument and voltage transformers, chokes and variable voltage transformers. The machine is equipped with the latest  PLC-system featuring a LCD-Touch-Display.

- PC-controlled Observation Module
- Built-in Touchless Magnetostrictive Measuring System
- PLC controlling unit
- User Planned Speed Modeling System
- LCD Control Panel
- Servo Motor System


A Wide Range Of Transformer Cores & Steel Qualities : The winder can operate within a wide range of steel qualities, producing outside transformer core diameters ranging from 39 mm to 210 mm with a maximum strip width of 80 mm. The machine will strictly adhere to the core winding specifications as it is manufactured to highest engineering parameters activating advanced electronics in logic control sequences.

Core Output : Integrated User Planned Speed Modeling System makes the winder one of the fastest among its class .

Service Requirements: Electrical:  380/415 3 phase 50Hz, plus neutral and earth (ground) rated at 20 amps per phase. De-coiler, supplied with the winding machine.
Air: Clean dry compressed air 120 psi (7-8 bar), volume 10 cfm.
Gas: Welding gas, standard high purity (99.995%) argon gas (Ar).

Sample Videos:

http://video.yahoo.com/watch/5477352/14414692

http://video.yahoo.com/watch/5484609/14430564

http://video.yahoo.com/watch/5479247/14418457


For any related questions , we would appreciate to get in cooperation with you .


Contact details for information :
Tel        : +90 262 654 18 13
Fax       : +90 212 355 07 25

email: info@core-winder.com
http://www.core-winder.com





     The New Generation
    Core Winder MAN2010
  • The cost & time saving clever solution
  • Built-in Touchless Magnetostrictive Measuring System
  • User Planned Speed Modeling System
  • Servo System
Cores in different sizes
